Nycolube 7000 Series
Nycolube 7000 Series Are Synthetic! Ubricants Based On Neopolyol Esters.
They Have Been Designed Specifically For Use in Refrigeration Systems Working With Hydro fluorocarbons (R134a, R404A, R407C, R410A, R507, R23 Etc...) As Cooling Fluid, The Traditional Mineral Oils and Alkyl Benzene Based Lubricants Being Not Compatible With These Coolants.
Their Excellent thermal And Hydrolytic Stability, Their Miscibility at Low temperature With HFC And Their Very Good Lubricity Provides Excellent Performance Levels and Energy Efficiency To The Ref Ri Geration Systems
Nycolube 7000 Are Available In Several Grades Of Viscosity To Suit A Wide Range Of Applications. Other Grades Can Be Developed To Meet the Requirements Of More Specialized Refrigeration Systems.
| Summary Of NL 7000 Series | ||||||||
| Designation | ISO VG | VISCOSITY @40 cmm2/s | VISCOSITY @100 cmm2/s | VISCOSITY INDEX | ACID NUMBER mg KOH/g | POUR POINT C | FLASH POINT COC C | MAIN APPLICATION |
| NL 7020 | 22 | 22 | 4.6 | 126 | 0.02 | -57 | 246 | REFRIGERATION COMPRESSORS WORKING WITH HFC REFRIGERANT |
| NL 7030 | 32 | 32 | 5.85 | 127 | 0.02 | -57 | 254 | |
| NL 7040 | 46 | 46 | 7.25 | 119 | 0.02 | -57 | 254 | |
| NL 7050 | 68 | 68 | 9.1 | 109 | 0.02 | -48 | 262 | |
| NL 7060 | 100 | 95 | 11 | 98 | 0.01 | -30 | 270 | RECIPROCATING FOR THE VISCOSITY GRADE UP TO 68. SCREW COMPRESSOR FOR THE HIGHER VISCOSITIES GRADES |
| NL 7075 | 170 | 174 | 15.7 | 91 | 0.02 | -30 | 276 | |
| VISCOSITY GRADES | 22 | 32 | 46 | 68 | 100 | 170 |
| TYPE OF COMPRESSORS | NYCOLUBE 7020 | NYCOLUBE 7030 | NYCOLUBE 7040 | NYCOLUBE 7050 | NYCOLUBE 7060 | NYCOLUBE 7075 |
| RECIPROCATING | 0 | 0 | 0 | 0 | ||
| CENTRIFUGAL | 0 | 0 | 0 | 0 | ||
| ROTARY | 0 | 0 | 0 | 0 | 0 | |
| SCREW | 0 | 0 | 0 | 0 | 0 | |
| SCROLL | 0 | 0 | 0 |
